| Model | 1325+rotary plasma |
| Working area | 1300*2500mm |
| Rotary device size | 240mm x6m |
| Plasma Generator | 100A/120A/160A/200A |
| Control system | FL430 |
| Rail type | Linear rails |
| Drive type | Stepper motor |
| Transmit | XY gear rack, Z ballscrew |
| Table | Blade table |
| Interface | USB port |
| Cutting thickness | Steel max 20mm , Aluminum max 10mm |
| Cutting speed | 0-8m/min |
| Moving speed | 0-20m/min |
| Lubrication system | Yes |
| Machine structure | thick steel tube welding |
| command code | G code |
| Machine size | 3000*2060*1400mm |
| packing size | 3150*2210*1610mm |
| Net/Gross weight | 1000kg / 1200kg |
